在板材行業的壓鑄生產中，壓鑄機與模溫機的匹配需綜合模具尺寸、材料特性、工藝溫度及控溫精度要求，核心原則是模溫機的加熱功率、循環流量及控溫范圍需完全覆蓋壓鑄工藝需求。以下是具體匹配邏輯及推薦方案：

一、匹配核心參數

1. 加熱功率計算
   模溫機的加熱功率需滿足模具從初始溫度升至目標溫度的能量需求，公式為：

• $m$：模具質量（kg）

• $c$：模具材料比熱容（鋼制模具約0.46kJ/kg·℃，鋁合金模具約0.88kJ/kg·℃）

• $\Delta T$：目標溫升（℃）

• $t$：升溫時間（分鐘）

• $\eta$：熱效率（取0.8-0.9）

• $1.2$：安全系數

示例：

• 鋼制模具（質量500kg）需從20℃升至200℃，升溫時間15分鐘：

需選擇**40kW以上模溫機**（如祝松機械40kW機型）。

2. 循環流量設計
循環流量需確保模具溫度均勻性，避免局部過熱或冷卻不足。流量計算公式為：

• $\rho$：介質密度（導熱油約850kg/m3）

• $c_p$：介質比熱容（導熱油約2.1kJ/kg·℃）
